Author Topic: Case Welding  (Read 1125 times)

Offline Stpltn250r

  • Trade Count: (0)
  • Trail Blazer
  • ******
  • Posts: 645
Case Welding
« on: October 06, 2012, 06:40:20 pm »
I have seen some pictures of cases **** on the clutch side around the crank bearing pocket. I went to pressure check my 540 and its **** around the bearing pocket on the clutch side. On the upper side closest to the crank balancer. Can the case be welded there?

I have asked a few guys already, not going against what they have said. Just looking to see what other people with this problem had done to resolve the issue.

I did not use a press. I used a heat gun and put the bearings in a freezer and dropped them in and did a little socket and hammer therapy to seat them in. Dont think that was the problem but Im not saying it wasnt. Crank was not welded, bearing pockets could be loose. But they have had inserts in them from T&N. Look like bronze or brass.

Here are some pictures.





Share on Facebook Share on Twitter


Offline Mitch Keller

  • Mitch Keller
  • Trade Count: (0)
  • Administrator
  • Trail Blazer
  • *****
  • Posts: 799
  • Love The Smell Of 927 and Race Fuel In The Morning
  • Location: Riverside Ca
Re: Case Welding
« Reply #1 on: October 06, 2012, 07:25:19 pm »
Did you talk to Mr Hall ?  This is also some of what Tudors has been known to repair.
Cases are becoming like gold now these days.
F Mitch Keller

Offline Rider414

  • Trade Count: (0)
  • Pro Member
  • ********
  • Posts: 984
  • Gender: Male
  • Location: Detroit, mi
Re: Case Welding
« Reply #2 on: October 06, 2012, 07:26:31 pm »
Damn that sucks - that's about where my original clutch side case was **** too. I guessed the original owner used a press and **** it.

MHR said he has done this repair...........might try hitting him up.
Ain't ever seen it......but I have heard it.

Offline Rider414

  • Trade Count: (0)
  • Pro Member
  • ********
  • Posts: 984
  • Gender: Male
  • Location: Detroit, mi
Re: Case Welding
« Reply #3 on: October 06, 2012, 07:30:48 pm »
Mine was **** near the bottom of the bearing pocket.

Ain't ever seen it......but I have heard it.

Offline SBLT500R

  • Trade Count: (0)
  • Store Admin / Classifieds / Services
  • Weekend Warrior
  • **
  • Posts: 215
Re: Case Welding
« Reply #4 on: October 06, 2012, 07:38:35 pm »
i would weld it up.  sucks you have to take it all apart again.  this only happen on cases that have inserts?  looks like it makes the cases weaker there.   also where did you support the case when you pressed the bearings in?  have to support the case near the bearing not just have it sit on the case mating surface.

i don't think it would matter, if you pressed it in or used a socket and hammer.  if the bearing goes in square, it will go right in and easy.  cocked will take more force and something could break, crack.   i always press in main bearings.  never broke a case.  used to use a hammer and socket, didn't like banging on the cases, so i got a little press.

Offline Stpltn250r

  • Trade Count: (0)
  • Trail Blazer
  • ******
  • Posts: 645
Re: Case Welding
« Reply #5 on: October 06, 2012, 07:48:44 pm »
Rider who fixed yours? What did it run?

Offline Cunningham_821

  • Trade Count: (0)
  • Range Rover
  • *****
  • Posts: 483
  • Gender: Male
  • I'm Slow
  • Location: Hastings pa
Re: Case Welding
« Reply #6 on: October 06, 2012, 11:27:22 pm »
said his origional side case sound like he got diffrent case.
#820
JR Motorsports
Halls Precision Racing

Offline Rider414

  • Trade Count: (0)
  • Pro Member
  • ********
  • Posts: 984
  • Gender: Male
  • Location: Detroit, mi
Re: Case Welding
« Reply #7 on: October 07, 2012, 07:14:19 am »
I got a different bottom end. I still have the broke case. I just got a different clutch side case to try to get a mis-matched set to work as a experiment.  :o

I forgot what MHR said he would do it for but it wasn't much at all. At the time I didn't want to wait.
Ain't ever seen it......but I have heard it.

Offline Pipe-Ster

  • Trade Count: (0)
  • Newbie
  • **
  • Posts: 23
Re: Case Welding
« Reply #8 on: October 09, 2012, 08:48:25 am »
weld it!!!

Offline Stpltn250r

  • Trade Count: (0)
  • Trail Blazer
  • ******
  • Posts: 645
Re: Case Welding
« Reply #9 on: October 09, 2012, 10:10:41 am »
think im gonna slap some toothpaste on it. that **** gets rock hard on the end of a tube. dont see why it wouldnt work on some cases!!!
