What Chain Slider Goes On This Swing Arm?

• What Chain Slider Goes On This Swing Arm?
  Posted by Dezsled on 01 Mar, 2013 18:29
• I noticed there is a threaded piece welded on the side of the swing arm, mines not like that. Anyone know what chain slider was used on this swing arm?

  http://www.ebay.com/itm/88-87-90-SUZUKI-LT500-R-QUADZILLA-REAR-SWINGARM-SWING-ARM-SHOCK-LINKAGE-CARRIER-/271148073550?pt=Motors_ATV_Parts_Accessories&hash=item3f21af424e&vxp=mtr

  Reason I ask is I'd like to gusset my swing arm where the oem chain slider holes crack/fatigue, I've welded the holes up and redrilled but I know it's gonna crack again. So I'd like to try a different chain slider that doesn't mount like the oem.




•

• #1 Reply
  Posted by cworobec on 01 Mar, 2013 19:30
• That's just an oem swinger that's 88-90, the later model chain sliders bolted on from the side. Just order a new oem slider.
•

• #2 Reply
  Posted by SBLT500R on 01 Mar, 2013 21:25
• 87 swingers **** so they updated the slider mount to the side.

  weld a 1/4 inch thick plate to the top of the arm then cut the slider ot fit.  did my buddies that way and its still holding up, no cracks.
•

• #3 Reply
  Posted by Dezsled on 02 Mar, 2013 08:07
• Thanks Shawn, cworobec.

  I think that idea is going to be the plan, thanks
•

• #4 Reply
  Posted by SBLT500R on 02 Mar, 2013 08:50
• forgot to add, i welded a threaded round piece to the side where the 88-90 slider mounts.  no more need for the threw bolt.
•
